LAZR 4G™ projector

Outdoor Projection System

Waterproof Projector

Professional IP rated video projector for permanent outdoor installation
Outdoor humidity & dust resistance, designed for outdoor use anywhere on the planet
Projector Body IP43 Ingress Protection Certified. All connectors IP68 Ingress Protection Certified

L A Z R 4G™

VIDEO MAPPING PROJECTOR
EUR24,900

  • Remote Management over the Internet
  • Video Mapping Software & Player
  • Multi-Projector Image Blending
  • Projection Mapping Scanner
  • Standalone Operation 24/7

Explore

L A Z R™

OUTDOOR PROJECTOR
EUR16,900

  • HDMI / HDBaseT signal input
  • madmapper's miniMAD compatible
  • Lightform LFC compatible
  • 3rd party media player connectivity 5V, 12V
  • Chromecast compatible (not available in the USA)

Explore

Overview & Dimensions

LAZR 4G projector - Dimensions: 530 x 675 x 240 mm. Weight: 24kg / 53lb
LAZR4G Outdoor Video Mapping Projector - Bottom View with Attachment Dimensions

Exploded View

Professional Outdoor Video Mapping Projector - Exploded View
Throw Distance Screen Calculator - Metric Units
Throw Distance Screen Calculator - Imperial Units

OPERATING
TEMPERATURE
RANGE













-20°C to +45°C
-4°F to 113°F

Planet Compatibility

LAZR Outdoor Projector

Outdoor Enclosure Box for Projector w/ Chromecast Inside

Robust Power Management

When power lost, the device goes to sleep. The device reboots to operation mode after the power supply is restored.

Technical Specification

Image Projection Technology RGB Laser DLP
Image Resolution 1920x 1200 WUXGA
Light Source Life 20000 h
Brightness 6000 ANSI lm
Throw Ratio 1.2 – 1.9
Power 550 W, 110 – 230V
Ingress Protection IP 43 body, IP 68 connectors
Weight 24 kg / 53 lb
Default Image Orientation Landscape Mode
Available Image Orientation Extension Portrait Mode Kit
